• Color: White
  • Output voltage: AC 220V
  • Capacity: 5KWH
  • Energy:5.5KW

Key attributes

System Voltage
 51.2 V Output Power Range 5-10kW
Grid connection Off grid, Hybrid grid Battery Type LiFePO4
Place of Origin Guangdong, China System Type wheel style/floor stand
Model Number YQD-5121001-LFOESS Brand Name Customized
Dimension (LWH) 550+492*450mm Weight 101KG
Type All-In-One Communication Port CAN, RS-232, Rs485
Protection Class IP65 Product name Home Energy Storage Battery System
Nominal Voltage 51.2V Capacity 100Ah
Battery Energy 5.12KWh Battery cell A- Grade
Inverter 5KW Pure Sine Wave Inverter Cycle life 6000 Cycles
Certification UN38.3,MSDS, IEC,CE,RoHs Warranty 5 Years
Protection BMS Protection

Packaging and delivery

Selling Units Single item Single package size 60X54X59 cm
Single gross weight 110.000 kg
